Applying M&S Filters
To clear your product and keep it safe from dirt particles, SKS has various types of stainless steel filter types from M&S in its collection. The filters can be used for hygienic process solutions such as food and beverage.
M&S distinguishes itself by the complete service they provide and their flexability. The filters can be entirely composed to suit the user and his process.
SKS categorizes three different types of filters:
- In-Line filters
- Square tube filters also known as angular tube filters
- Dirt collectors
The filters and strainers can be composed with different connections and seals. The materials that comes in contact with the product consist of stainless steel 304 or 316. By default the filters will be delivered with EPDM seals and a perferation of 1,5mm.
Optionally their are other seals like NBR or FKM available as well as different perferation options. If you need less perferation we can provide them with different mesh and layer options.
| Artikelnr. | Omschrijving | Onderdeel | Maatvoering | Materiaalsoort | Aansluiting | Voorraad |
|---|---|---|---|---|---|---|
|
13334230
|
Haaks buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN25 1.4307 (304L)
|
Buisfilter haaks compleet
|
DN25 (ø 29 mm)
|
304 (L)
|
Draad / Draad
|
|
|
13334234
|
Haaks buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN40 1.4307 (304L)
|
Buisfilter haaks compleet
|
DN40 (ø 41 mm)
|
304 (L)
|
Draad / Draad
|
|
|
13334235MS
|
Haaks buisfilter Dr/Dr
0,2x0,125 binnen compl.gesold.
DN40 1.4307 (304L)
|
Buisfilter haaks compleet
|
DN50 (ø 53 mm)
|
316 (L)
|
Draad / Draad
|
|
|
13334236
|
Haaks buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN50 1.4307 (304L)
|
Buisfilter haaks compleet
|
DN50 (ø 53 mm)
|
304 (L)
|
Draad / Draad
|
|
|
13334237MS
|
Haaks buisfilter Las/Las
Zeefinzet 1,5mm perforatie
2 1/2" 1.4307 (304L)
|
Buisfilter haaks compleet
|
2,5" (ø 63,5 mm)
|
304 (L)
|
Las / Las
|
|
|
13334238
|
Haaks buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN65 1.4307 (304L)
|
Buisfilter haaks compleet
|
DN65 (ø 70 mm)
|
304 (L)
|
Draad / Draad
|
|
|
13334240
|
Haaks buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN80 1.4307 (304L)
|
Buisfilter haaks compleet
|
DN80 (ø 85 mm)
|
304 (L)
|
Draad / Draad
|
|
|
13334242
|
Haaks buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN100 1.4307 (304L)
|
Buisfilter haaks compleet
|
DN100 (ø 104 mm)
|
304 (L)
|
Draad / Draad
|
|
|
13334246
|
Haaks buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN150 1.4307 (304L)
|
Buisfilter haaks compleet
|
DN150 (ø 154 mm)
|
304 (L)
|
Draad / Draad
|
|
|
13338211MS
|
In-line buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN50 1.4404 (316L)
|
|
DN50 (ø 53 mm)
|
316 (L)
|
Draad / Draad
|
|
|
13338230
|
Haaks buisfilter Dr/Dr
Zeefinzet 1,5mm perforatie
DN25 1.4404 (316L)
|
Buisfilter haaks compleet
|
DN25 (ø 29 mm)
|
316 (L)
|
Draad / Draad
|
|
|
13338230BW
|
Haaks buisfilter Las/Las
Zeefinzet 1,5mm perforatie
DN25 1.4404 (316L)
|
Buisfilter haaks compleet
|
DN40 (ø 41 mm)
|
316 (L)
|
Las / Las
|
|
| Artikelnr. | Omschrijving | Maatvoering | Elastomeer | Voorraad |
|---|---|---|---|---|
|
16338540MS
|
Filterhuis haaks buis filter
Las/Las
DN80 1.4404 (316L)
|
|
|
|
|
13340261MS
|
Onderdeel vuilvanger
Pakkingset type 6030
DN50 FKM
|
|
|
|
|
13338542MS
|
Filterhuis haaks buis filter
Draad/Draad
DN100 1.4404 (316L)
|
|
|
|
|
13338713MS
|
Huis vuilvanger
Las/las
DN65 1.4404 (316L)
|
|
|
|
|
13330692MS
|
Onderdeel haaks buisfilter
Afdichtings set EPDM DN100
|
|
|
|
|
13330696MS
|
Onderdeel haaks buisfilter
Afdichtings set EPDM DN150
|
|
|
|
|
13334532MS
|
Filterhuis haaks buis filter
Draad/Draad
DN32 1.4307 (304L)
|
|
|
|
|
13330682MS
|
Onderdeel haaks buisfilter
Afdichtings set EPDM DN25
|
|
|
|
|
16338536MS
|
Filterhuis haaks buis filter
Las/Las
DN50 1.4404 (316L)
|
|
|
|
|
13340692MS
|
Onderdeel haaks buisfilter
Afdichtings set Viton DN100
|
|
|
|
|
13338535MS
|
Filterhuis haaks buis filter
2'' / 50,8 las/las 316L
|
|
|
|
|
13338690
|
Onderdeel t.b.v. haaks buisfilter
Zeefinzet 1,5mm perforatie
DN80/3" 1.4404 (316L)
|
|
|
|
