Reducer
Weld Fittings (Reducer)
Weld fittings such as straight pieces, elbows, tees, and crosses that are precisely machined and finished to fit standardized pipe diameters, creating strong and reliable connections.
Specifications:
- Sizes: 1/8” – 1”
- Material: 316L, 316L VIM/VAR (Double Melt) (product contact parts)
- Surface Finish: Ra ≤ 0.25µm standard passivated, or Ra ≤ 0.13µm electropolished
- Custom versions available on request
- The fittings are cleaned and packaged under cleanroom conditions. Additionally, they are suitable for processing with orbital welding equipment.
Certificates:
MTR (Mill Test Report) or 3.1 certificate according to EN 10204 (product contact parts)
| Articlenr. | Description | Dimensions | Dimensions 2 | Material type | Internal surface | Stock |
|---|---|---|---|---|---|---|
|
7201514105
|
UHP Forged fitting
Reducer
3/8"x1/4" (9,53 x 0,89 / 6,35 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
3/8" (ø 9,53 mm)
|
1/4" (ø 6,35 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514107
|
UHP Forged fitting
Reducer
1/2"x1/4" (12,7 x 1,24 / 6,35 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
1/2" (ø 12,7 mm)
|
1/4" (ø 6,35 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514109
|
UHP Forged fitting
Reducer
1/2"x3/8" (12,7 x 1,24 / 9,53 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
1/2" (ø 12,7 mm)
|
3/8" (ø 9,53 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514111
|
UHP Forged fitting
Reducer
3/4"x1/4" (19,05 x 1,65 / 6,35 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
3/4" (ø 19,05 mm)
|
1/4" (ø 6,35 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514113
|
UHP Forged fitting
Reducer
3/4"x3/8" (19,05 x 1,65 / 9,53 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
3/4" (ø 19,05 mm)
|
3/8" (ø 9,53 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514115
|
UHP Forged fitting
Reducer
3/4"x1/2" (19,05 x 1,65 / 12,7 x 1,24)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
3/4" (ø 19,05 mm)
|
1/2" (ø 12,7 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514117
|
UHP Forged fitting
Reducer
1"x1/4" (25,4 x 1,65 / 6,35 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
1" (ø 25,4 mm)
|
1/4" (ø 6,35 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514119
|
UHP Forged fitting
Reducer
1"x3/8" (25,4 x 1,65 / 9,53 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
1" (ø 25,4 mm)
|
3/8" (ø 9,53 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514121
|
UHP Forged fitting
Reducer
1"x1/2" (25,4 x 1,65 / 12,7 x 1,24)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
1" (ø 25,4 mm)
|
1/2" (ø 12,7 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514123
|
UHP Forged fitting
Reducer
1"x3/4" (25,4 x 1,65 / 19,05 x 1,65)
316L Single melt
Internal surface Ra ≤ 0,25µm
Standard pasivated
|
1" (ø 25,4 mm)
|
3/4" (ø 19,07 mm)
|
316L Single melt
|
Ra ≤ 0,25µm
|
|
|
7201514205
|
UHP Forged fitting
Reducer
3/8"x1/4" (9,53 x 0,89 / 6,35 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,13µm
Electro polished (EP)
|
3/8" (ø 9,53 mm)
|
1/4" (ø 6,35 mm)
|
316L Single melt
|
Ra ≤ 0,13µm
|
|
|
7201514207
|
UHP Forged fitting
Reducer
1/2"x1/4" (12,7 x 1,24 / 6,35 x 0,89)
316L Single melt
Internal surface Ra ≤ 0,13µm
Electro polished (EP)
|
1/2" (ø 12,7 mm)
|
1/4" (ø 6,35 mm)
|
316L Single melt
|
Ra ≤ 0,13µm
|
|
